Look for software that holds one job record from enquiry to dispatch, prices from sheet area and offcut, locks the drawing revision and prints cut and bend lists. Weld and coating records ride along. Dispatch uses the same job. Without those, a spreadsheet stays cheaper.
Quotes that start from the sheet, not a guess
A fabricator sells steel, aluminium and stainless that has been cut, bent and finished, so the quote must begin from the grade, gauge and sheet size you buy. Weight per part is half the story.
Ask how the software treats offcut, because a part nested on a 2500 by 1250 sheet consumes more than its own area, plus the skeleton left after cutting. Good tools let the estimator set a utilisation figure per material and then show what scrap does to the price of each line.
Split cutting, bending and setup. A laser job with forty bends on a press brake is a different animal from a flat plate with holes, and the quote should show that gap.
- Grade, thickness and sheet size per line
- Editable utilisation and offcut allowance
- Laser time, bends and setups priced apart
- Powder coat or galvanising as outside work
- Quote converts to a job unchanged
One drawing revision that the whole shop sees
Most floor errors trace back to a printout. Someone cut from revision B while the customer had already sent revision D, and nobody at the laser or the press brake knew a newer drawing existed. Software should show the current revision on every traveller and block the old one, so an operator cannot nest a stale DXF by accident.
Look for a place to attach the DXF, the PDF and the customer’s change note to the job, so the history stays with the work. When a revision arrives, the system should flag every nested sheet, every part already cut and every bent part waiting at the weld bay.
That flag matters more than any report. It gives the planner a chance to stop work before another sheet of stainless goes under the laser, which is the cheapest moment to catch an error.
Cut lists, bend lists and a traveller that follows the job
A job moves from nesting to the laser, then deburring, the press brake, welding, finishing and packing, and each stop needs its own list of parts. Typed lists breed quantity errors.
Ask whether the system prints a traveller per job with part numbers, quantities and bend sequence, and lets operators mark a stage done on a tablet. A scanned card works too.
Short runs change the maths. If your shop runs many small jobs a day, entry time per stage must be measured in seconds, because minutes at the bench will push people back to paper.
- Part list and quantity per stage
- Bend sequence and brake tooling note
- Stage status marked by operators
- Rework and rejects booked to the job
Weld, coating and inspection records
Buyers of electrical enclosures, food equipment and structural supports increasingly ask for proof of how each seam was welded and each panel was finished. Which welder ran this seam? Which coating batch was used?
A job shop needs no full quality suite, yet it should store welder name, procedure reference, inspection result and coating batch against the job number and print one pack.
Without that, the records live in a folder on someone’s desk, and a customer complaint six months later turns into a search party.
Dispatch tied to the same job, and where spreadsheets stop
Dispatch closes the job. If the delivery note is typed separately, partial deliveries and short shipments never match the order, and the invoice waits while someone reconciles them by hand. One record fixes that.
A spreadsheet copes while one person holds the whole shop in their head, but it stops coping when a second estimator, a second shift or a second laser appears. Version clashes and missing rows follow.
Before you shortlist anything, list your last ten jobs and mark where each one went wrong, then use that list as your demo script. Ask every vendor to run it.
Job shop software shortlist sheet
One sheet of paper carries five blocks for the quote, the drawing revision, the shop floor, the records pack and dispatch, each listing the features above. Columns hold one vendor each. A final column records what the demo showed on your own part, and the last row lists your ten problem jobs from the past year.
Open a blank worksheet to printQuestions owners ask
Do I need nesting built into the software?
No, not always. Nesting can stay in the laser package. What you need is a way to bring sheet usage back into the job, so the quoted material and the material actually consumed can be compared line by line.
Is a ready product enough for a fabrication shop?
A ready product often suffices when your flow is cut, bend, weld, finish and dispatch, but custom work makes sense when you run unusual steps. Inspection packs are one example.
How long does a shop take to start using it?
Begin with one machine group. Add stage tracking and records once the team trusts the first part, because rushing the whole floor into use in a single week usually fails.
